NEW 2025 Orbea Kemen ADV 20 MID 28mph Hybrid eBike - 630Wh - Shimano EP600

NEW 2025 Orbea Kemen ADV 20 MID 28mph Hybrid eBike - 630Wh - Shimano EP600

$ 3,299.97 USD
$ 4,399.00 USD $ 3,299.97 USD
Sale Sold out
Shipping calculated at checkout.
Color
Size
ATC SKU: 210000061156
EAN: 8434446808081
MFG. SKU: S70603VU

PRODUCT DETAILS

Kemen Adv is equally at home cutting through the city or exploring the hills. The powerful Shimano EP motor and 630Wh battery open up a world of possibilities, and our wide range of accessories make it simple to configure Kemen for whatever your day holds.

BUILD KIT:

  • Frame: Orbea Kemen Mid Bar, Shimano Steps, Integrated battery, Hydroformed Alloy 6061 series, Internal Cable Routing, Boost 148x12, carrier and kickstand compatible
  • Fork: SR Suntour XCR34 100mm Air Q15x110
  • Steerer Tube: FSA 1-1/2" Integrated Aluminium Cup
  • Battery: Orbea Internal 630Wh
  • Range Extender: N/A
  • Motor: Shimano EP600
  • Display: N/A
  • Charger: Orbea 2.Generation eBike Smart charger 42V/2-4A
  • Remote: EN600-L
  • Chainring: FSA Steel Megatooth 44t w/chainguard
  • Crank: FSA CK-752 Shimano EP600/801 170mm
  • Shifters: Shimano Cues SL-U6000
  • Cassette: Shimano CS-LG400 11-50t 11-Speed
  • Rear Derailleur: Shimano Cues U6000 GS Shadow
  • Chain: KMC eGlide
  • Handlebar: Orbea Urban, Integrated Light, Rise 50, Width 760
  • Brakes: Magura AT2 Hydraulic Disc Easy Route Connection
  • Wheels: Alloy, Tubeless, 29", 29c, 32H
  • Tyres: Schwalbe Johnny Watts LR, 60-622, Reflective Tape
  • Pedals: VP-537 Black
  • Rear Carrier: Orbea RR-02 Alloy, w/MIK HD and MIK Side and Ortlieb QL3.1 system. Max. 30Kg
  • Mudguard: Curana Apollo Orbit 70mm
  • Front Position Light: Orbea integrated, USB-C charging point
  • Front Light: Supernova Starstream Pro, High Beam
  • Rear Light: Supernova TL3 Z
  • Quick Stand: Massload rear adjustable
  • Seatpost: Alloy, 31.6mm, Setback 0
  • Saddle: Selle Royal Vivo Ergo

SIZING: Orbea recommends the following sizes based on rider height:

  • SM: 5'0" - 5'8"
  • MD: 5'5" - 6'0"
  • LG: 5'9" - 6'5"
