NEW 2026 Orbea DENNA M20i 28mph Electric Carbon Gravel Bike

NEW 2026 Orbea DENNA M20i 28mph Electric Carbon Gravel Bike

$ 7,978.95 USD
$ 7,978.95 USD $ 7,978.95 USD
Sale Sold out
Shipping calculated at checkout.
Size
Color
ATC SKU: 210000069603

PRODUCT DETAILS

Denna is all about removing limits. Gravel-tuned assistance offers power for the steepest climbs, and range for the longest rides. Wide tire clearance and a frame designed for a smooth ride make big days in the saddle a pleasure.

BUILD KIT:

  • Frame: Orbea Denna, Thru Axle 12mm x 142mm rear, thread M12xP1, internal cable routing
  • Fork: Orbea Denna OMR ICR, full carbon, 1-1/8" - 1.5" tapered head tube compatible, Thru Axle 12x100mm, thread M12xP1
  • Steerer tube: FSA 1.5" Integrated Aluminium Cup
  • Battery: Orbea Internal 420Wh
  • Range Extender: N/A
  • Motor: Shimano EP801
  • Display: N/A
  • Charger: Orbea 2nd Generation eBike Smart Charger 42V/2–4A
  • Remote: EN600-L
  • Chainring: Alloy EP8 42t
  • Crank: Shimano Steps EM600
  • Shifters: Shimano ST-8170
  • Cassette: Shimano CS-M8100 10-51t 12-Speed
  • Rear derailleur: Shimano XT M8260 SGS
  • Chain: Shimano M6100
  • Chainguide: Orbea eBike chainguide
  • Handlebar: OC Gravel GR10 Carbon, Reach 70, Drop 110
  • Stem: OC Road Performance RP10, -8º
  • Brakes: Shimano R8170 Hydraulic Disc
  • Brakes Configuration: N/A
  • Wheels: Oquo Road Control RC30TEAM
  • Tyres: Vittoria Terreno Dry Gravel G2.0 TLR 700x45c
  • Front Wheel Axle: Orbea Thru Axle 12x100mm M12xP1 Hollow
  • Rear Wheel Axle: Orbea Thru Axle 12x142mm M12xP1 Solid inner threaded
  • Seatpost: OC Performance XP10 Carbon, 27.2mm, Setback 0
  • Saddle: Selle San Marco Shortfit 2.0 Start Up Off Road Xilite
  • Mudguard: N/A
  • Handlebar Tape: Orbea Anti-Slippery/Shock Proof
  • Storage: N/A

SIZING: Orbea recommends the following sizes based on rider height

  • XS: 5'1" – 5'5"
  • SM: 5'6" – 5'8"
  • MD: 5'8" – 5'10"
  • LG: 5'11" – 6'1"
  • XL: 6'1" – 6'3"
  • XXL: 6'4" – 6'9"
