NEW 2027 Orbea Rallon E-TEAM Carbon Mountain Bike - Shimano XT M8200

The 2027 Orbea Rallon E-TEAM is a race-ready carbon enduro bike built to descend at full pace, pairing a 180mm Fox 38 Factory fork and a Fox Float X2 air shock with a full Shimano XT drivetrain. With Orbea's Concentric rear suspension, Pure Gravity geometry, lightweight Oquo wheels, and a dropper post, the Rallon E-TEAM is a hard-charging 29er ready for enduro race courses and the steepest, roughest trails.

OMR Carbon Enduro Frame

Orbea's Rallon OMR carbon frame uses Pure Gravity geometry, the Concentric rear suspension layout, and an Attitude Adjust flip chip to fine-tune the ride. Boost 12x148 spacing, ISCG05 mounts, 29" wheels, and a 442mm chainstay deliver a planted, confident, race-ready enduro platform.

180mm Fox 38 + Float X2 Shock

A burly 180mm Fox 38 Float Factory fork with Kashima coating and a high-performance Fox Float X2 Factory rear shock deliver supremely controlled, fully-tunable gravity suspension, while aggressive Schwalbe Magic Mary 29x2.50" Ultra Soft tires keep you planted in steep, loose terrain.

Shimano XT 12-Speed + 4-Piston Brakes

A full Shimano XT M8200 drivetrain delivers crisp, precise shifting across a wide 10-51t range, and Shimano XT 4-piston hydraulic disc brakes provide powerful, confident stopping. Lightweight Oquo MC32TEAM wheels, a carbon handlebar, and a Race Face Turbine crank sharpen the package.

Available in three colorways - White - Black, Green - Purple, and Nickel - plus a custom MyO option, in sizes S-XL.

KEY FEATURES:

• Orbea Rallon OMR carbon enduro frame, Pure Gravity geometry, Attitude Adjust
• 442mm chainstay (also offered as a longer-chainstay Rallon 450)
• 180mm Fox 38 Float Factory fork + Fox Float X2 Factory shock
• Dropper seatpost with Shimano remote
• Shimano XT M8200 12-speed drivetrain
• Shimano XT 4-piston hydraulic disc brakes
• Oquo Mountain Control MC32TEAM wheels
• Schwalbe Magic Mary 29x2.50" Ultra Soft tires, sizes S-XL

BUILD KIT:

• Frame: Orbea Rallon OMR carbon, Pure Gravity geometry, Attitude Adjust, 442mm chainstay, Boost 12x148, ISCG05
• Fork: Fox 38 Float Factory 180mm, Grip X2, Kashima, 15x110
• Shock: Fox Float X2 Factory Trunnion, 2-Pos Adjust, Kashima, 205x62.5mm
• Headset: Alloy 1-1/2"
• Stem: OC Mountain Control MC11 Alu SL, 0deg
• Handlebar: OC Mountain Control MC10 Carbon, Rise 35, 800mm
• Brakes: Shimano XT 8220 4-Piston Hydraulic Disc
• Rear Derailleur: Shimano XT M8200 SGS Shadow Plus
• Shifter: Shimano XT M8200 I-Spec EV
• Cassette: Shimano CS-M7200 10-51t 12-Speed
• Chain: Shimano M7100
• Crankset: Race Face Turbine, 32t
• Wheels: Oquo Mountain Control MC32TEAM
• Tires: Schwalbe Magic Mary Radial 29x2.50", Gravity Pro, Ultra Soft
• Seatpost: Dropper post with Shimano SL-MT500 remote
• Saddle: Fizik Terra Ridon X5 145mm

SIZING: Orbea's recommended rider height by size (approximate):

• S: 155-168 cm (5'1"-5'6")
• M: 165-178 cm (5'5"-5'10")
• L: 175-188 cm (5'9"-6'2")
• XL: 185-198 cm (6'1"-6'6")

FREQUENTLY ASKED:

• What kind of bike is the Rallon? It's an aggressive carbon enduro race bike - 180mm front travel, Pure Gravity geometry, and a Fox 38 fork - built to descend at race pace while still pedaling to the top.
• What is the difference between the Rallon and the Rallon 450? The 450 uses a longer 450mm chainstay for added high-speed stability; this E-TEAM uses the standard 442mm chainstay. Both share the same build and travel.
• Does it come with a dropper post? Yes - the Rallon E-TEAM includes a dropper seatpost with a Shimano remote.
• What makes the E-TEAM special? A Fox Float X2 shock, a full Shimano XT M8200 drivetrain with XT 4-piston brakes, lightweight Oquo MC32TEAM wheels, a carbon handlebar, and a Race Face Turbine crank.
• How does the E-LTD step up from the E-TEAM? The E-LTD adds an electronic Fox Float X2 Live Valve Neo shock, a wireless SRAM X0 Eagle AXS drivetrain, and Shimano XTR brakes.
• What's new for 2027? Updated 2027 Rallon platform with Attitude Adjust geometry and new colorways.
