NEW All-City Zig Zag 105 - Honeydew Bling Road Bike

NEW All-City Zig Zag 105 - Honeydew Bling Road Bike

Regular price $ 2,319.97 USD
Regular price $ 2,899.00 USD Sale price $ 2,319.97 USD
Sale Sold out
Size
SKU: 210000043740
Special Order - In Warehouse or Pre-Order - contact us for ETA

PRODUCT DETAILS

The Zig Zag is All-City’s answer to what a Modern Endurance Steel Road Bike should be. Elegant and eye-catching, it’s a ripping-fast and efficient machine built to shield the rider from road chatter and unnecessary fatigue. Designed for speed, style, and maximum comfort, the Zig Zag allows riders to go further, faster, and have more fun.

  • A.C.E. Tubing — Our proprietary heat-treated, air-hardened, extruded steel tubing that we custom designed for riding and racing
  • Whisky No.9 RD+ carbon fork
  • Whisky No.7 handlebar, stem and seatpost
  • A classic road silhouette blends with a contemporary road geo to balance power with comfort for long days in the saddle or attacks off the front
  • Clearance for 700c x 35mm tires without fenders; 700c x 32mm with fenders
  • Custom head badge, Signature dropouts, Signature brazed-on seat collar, pump peg, two bottle bosses, and hidden fender mounts

Build Kit

  • Frame : All-City A.C.E. Air-Hardened, Custom, Extruded steel
  • Fork : Whisky No.9 RD+ Thru-Axle Tapered
  • Front Derailleur : Shimano 105 R7000
  • Rear Derailleur : Shimano 105 R7000
  • Cassette/Cog : Shimano R7000 11-32
  • Chain : Shimano HG601
  • Crankset : Shimano 105 R7000 52-36
  • Bottom Brcket : Shimano RS500
  • Shifter(s) : Shimano 105 R7000
  • Brakes : Shimano 105 R7000 Hydro
  • Rotors : Shimano 6-bolt SM-RT26 160 rotors
  • Headset : Cane Creek 40 Series
  • Stem : Whisky No.7 Black Alloy Stem; ±6° Rise
  • Handlebar : Whisky No.7 Black 6° Flair Drop Bar
  • Seatpost : Whisky No.7 Black Alloy Seatpost
  • Saddle : Black with Chromo Rails
  • Wheels : WTB ST Light i19 700c 28h rims, All City Go Devil hubs
  • Tires : Teravail Rampart 700x28 60tpi Light and Supple

Sizing

Please note this is an approximate range and the buyer is responsible for verifying the fit before purchase

  • 46cm 5' - 5'5"
  • 49cm 5'2" - 5'8"
  • 52cm 5'6" - 5'11"
  • 55cm 5'9" - 6'1"
  • 58cm 5'11 - 6'4"
  • 61cm 6'1" - 6'6"

Geometry

Frame measurements (mm) 46cm 49cm 52cm 55cm 58cm 61cm
A. BB Drop 70 70 70 70 70 70
B. Chainstay Length 415 415 415 415 420 420
C. Fork Length - Axle to Crown 386 386 386 386 386 386
D. Fork Offset 51 51 51 51 51 51
E. Head Tube Angle (deg) 70 71 72 72 72.5 72.5
F. Headtube Length 106 121 140 160.5 185.5 210.5
G. Reach 375 377 384 389 400 415
H. Seat Tube Angle (deg) 75.5 74 73.5 73 72.5 72.5
I. Seat Tube Length - Center to Top 460 490 520 550 580 610
J. Stack 524 540 562 583 607 631
K. Standover 736.9 761.4 787.7 813.4 840.1 866.4
L. Top Tube Length (Effective) 520 530 545 560 580 605
M. Wheelbase 1003.3 1006.8 1011.3 1019.35 1043.5 1065.6
Component measurements (mm)
Crank Arm Length 165 170 172.5 172.5 175 175
Handlebar Width (cm) 38 40 40 42 44 46
Seatpost Offset 0 18 18 18 18 18
Stem Length 70 80 90 100 110 110
Stem Angle (deg) 6 6 6 6 6 6
