NEW KHS Winslow Hardtail Mountain Bike

Build Kit

• Frame : 6061 Aluminum w/Custom Formed T/T & D/T, w/Replaceable Derailleur Hanger, XS-S:27.5”, M-XL:29”, Internal Cable Routing
• Fork : SR XCT30, HLO. 100mm, Hydraulic Lock-Out, Preload Adjust XS-S:27.5”, M-XL:29”
• Rear Derailleur : S-Ride RD-M410C, 9-Speed

• Cassette/Cog : CS-M300C 11-46T, 9-Speed
• Chain : KMC X9 w/MissingLink
• Crankset : Samox Forged, 30T Narrow/Wide, XS-S:170, M-XL:175
• Bottom Brcket : Cartridge Bearing
• Shifter(s) : S-Ride SL-M300C, 9-Speed
• Brakes Levers : Shimano MT200
• Brakes : Shimano MT200 Hydraulic Disc
• Rotors : 180/160mm Rotors Wave 12
• Headset : Threadless ZeroStack, 1-1/8"
• Stem : Aluminum Threadless 4-bolt, 6-degree, 31.8, XS:60mm, S-M:75mm, L-XL:90mm
• Handlebar : KHS Aluminum Riser, 31.8, 720x20mm, Ladies:680x20mm
• Seatpost : KHS Aluminum Micro-Adjust 31.6x350
• Saddle : KHS Sport
• Front Wheel : Aluminum Disc Double Wall, XS-S: 27.5x32H, M-XL: 29x32H
• Rear Wheel : Aluminum Disc Double Wall, XS-S: 27.5x32H, M-XL: 29x32H
• Tires : Kenda Saber, XS-S: 27.5x2.2, M-XL: 29x2.2

Sizing

• XS: 4'10" to 5'3"
• S: 5'2" to 5'7"
• M: 5'5" to 5'10"
• L: 5'8" to 6'1"
• XL: 5'11" to 6'4"

*Please note this is an approximate range and the buyer is responsible for verifying the fit before purchase.
