NEW Surly Bridge Club 700c - Black Touring Bike
NEW Surly Bridge Club 700c - Black Touring Bike
Regular price
$ 1,449.00 USD
Regular price
$ 1,449.00 USD
Sale price
$ 1,449.00 USD
Unit price
/
per
SKU: 210000038257
Special Order - In Warehouse or Pre-Order - contact us for ETA
PRODUCT DETAILS
As a highly versatile touring bike, the Bridge Club hits the sweet spot that separates on- and off-road excursions. The simplistic design makes it fully adept to handle a full rack and pannier setup, frame bags, or any combination of the two. It doesn’t feel sluggish on paved shortcuts, but can also hold its own on dirt detours. If you’re feeling a little zesty on your next road tour, you won’t be ill-prepared for reroutes through the woods. The Bridge Club is designed to handle it all.
- 100% Surly 4130 CroMoly frame, main triangle is double-butted; 1-1/8" threadless CroMoly fork
- Rack, fender, and four sets of Three-Pack mounts
- Disc brake-specific, single-position vertical rear dropout makes it less intimidating than other bikes in the category
- Durable 700c wheel build, including Surly Extra Terrestrial 700 x 41mm tires
- Swept-back comfort and off-road capable Surly Terminal Handlebar
- Clearance for 700 x 47mm (with or without fenders) or 27.5 x 2.8" tires (27.5 x 2.6" with fenders)
Build Kit
- Frame : 100% Surly Chromoly Steel, Natch tubing, double-butted main triangle, TIG welded, E.D. coated
- Fork : 100% Surly Chromoly Steel, Natch tubing, double-butted tapered fork blades, TIG welded, E.D. coated
- Rear Derailleur : Shimano Deore M5100 Shadow Plus
- Cassette : Shimano Deore CSM5100 11-51t
- Chain : KMC X11 EPT
- Crankset : Shimano Deore M5100 32t
- Bottom Brcket : Shimano BSA
- Shifter(s) : Shimano Deore M5100 Rapid Fire
- Brakes Levers : Tektro HD-M275
- Brakes : Tektro HD-M275
- Rotors : 160mm F/R
- Headset : Cane Creek 40
- Stem : Promax, 31.8mm
- Handlebar : Surly Terminal Bar
- Seatpost : Promax, 27.2mm
- Saddle : WTB Volt 142
- Wheels : WTB ST i21 TCS, Novatech Hubs
- Tires : Surly Extraterrestrial 700x41, 60tpi Tubeless Ready
Sizing
Based on traditional geometry . Please note this is an approximate range and the buyer is responsible for verifying the fit before purchase.
- XS: 5' - 5'5"
- SM: 5'4" - 5'8"
- MD: 5'7" - 6'
- LG: 5'11" - 6'3"
- XL: 6'2" - 6'6"
Geometry
Frame measurements (mm) | XS | SM | MD | LG | XL |
A. BB Drop | 60 | 60 | 60 | 60 | 60 |
B. Chainstay Length | 435 | 435 | 435 | 435 | 435 |
C. Fork Length - Axle to Crown | 420 | 420 | 420 | 420 | 420 |
D. Fork Offset | 43 | 43 | 43 | 43 | 43 |
E. Head Tube Angle (deg) | 70 | 71 | 71 | 71 | 71 |
F. Headtube Length | 110 | 120 | 130 | 145 | 165 |
G. Reach | 376 | 397 | 419 | 434.5 | 444 |
H. Seat Tube Angle (deg) | 73 | 73 | 73 | 73 | 73 |
I. Seat Tube Length - Center to Top | 335.6 | 406.4 | 457.2 | 508 | 558.8 |
J. Stack | 553 | 567 | 576 | 590 | 609 |
K. Standover | 709 | 750.5 | 780 | 812 | 845.5 |
L. Top Tube Length (Effective) | 545 | 570 | 595 | 615 | 630 |
M. Wheelbase | 1032 | 1047.5 | 1073 | 1093 | 1109 |
Component measurements (mm)
|
|||||
Crank Arm Length | 170 | 170 | 175 | 175 | 175 |
Handlebar Width | 718 | 718 | 735 | 735 | 735 |
Handlebar Rise / Drop | - | - | - | - | - |
Stem Length | 80 | 80 | 90 | 90 | 90 |
Stem Angle (deg) | 6 | 6 | 6 | 6 | 6 |
